Mini concrete pump for sale

The mini concrete pump is of light weight, small volume and high maneuverability. Especially in the case of short-distance pumping, the low cost of pumping is more economical and energy-saving, which effectively avoids the useless power consumption of large pump trucks during long-distance pumping and the moving costs caused by their own weight. Due to its low cost, it saves a large amount of initial investment funds for the majority of users and lays a strong foundation for short-term recovery of costs.

Main features

1. The concrete boom pump truck adopts the German Elephant closed hydraulic system and the main oil pump of the German Rexroth A4VG125. The pumping speed is fast, the working efficiency is high, the pumping is reliable and stable, the reversing can be almost without impact.

2. The boom of the concrete boom pump truck adopts M-shaped structure design, and the material is 960 high-strength steel plate, which has high strength and good flexibility. The M-shaped boom is flexible and can be easily used in various difficult construction sites ( Narrow sites, closed workshops and construction sites with obstacles like high-voltage lines).

3. Boom and outrigger hydraulic system: The boom adopts a load-sensitive proportional control system, which makes the boom run at a free speed and has excellent operating performance. Not only can realize infinitely variable speed remote control, but also can realize emergency manual operation in emergency situations.

Considerate design

1. The concrete boom pump truck adopts the X outrigger with a small footprint, and the unique one-sided support design. The side that does not pump has no need to open he outrigger, requiring smaller space compared with other models.

2. The outrigger hydraulic cylinder is built-in and can play a protective role.

3. The hydraulic oil tank is built into the large frame of the vehicle body, which can play a role in heat dissipation. The material of the transfer case is made of aluminum, which also plays a good role in heat dissipation. The hydraulic oil in the car has a water-cooled and air-cooled dual heat dissipation system. It is for customers to use pump trucks for super long construction operations.

4. The body of the concrete boom pump truck has a shifting roof design, which is convenient for the pump truck to move in a narrow environment.

5. It is designed with a high-pressure water gun, which is driven by a hydraulic motor, which is stronger than the pressure driven by pneumatic equipment, and is convenient for cleaning the concrete on the pump truck after construction.

20m Concrete pump Technical Parameter

Main Parts

Index

Specific value

Chassis

Chassis model

EQ5161TZZKJ

Engine Type

YC6J180-46

Engine Power

132 kw

Engine Displacement

6494 ml

Max.Travel Speed

80km/h

Min.Turning Radius

8.2m

Approach/Departure Angle

26°/13°

Tyre Type

8.25R20

Drive Type

4x2

Wheel Base

4700 mm

Boom system

Max.vertical Reach

21.1m

max.horizontal Reach

17.5m

Reach depth

7.5m

Unfolding Height

10.1m

Arm Section Articulation

90/180/180

Boom Control mode

manual,wire and wireless remote control are all available

Boom Type

M

Slewing Range

365°

Front Outriggers Spread

4024 mm

Rear Outriggers spread

3100mm

Longitudinal distance between front and rear outriggers

4024×3100

Legs Open Type

X

End Hose Length

3m

Arm Attached Pipeline Diameter

125 mm

Boom Steel

900#

Electrical control system

Power Supply

Chassis provides power supply.

Control module

Siemens

Working Voltage

DC24V

Relay

Siemens

Proximity Switch

Turk

Wireless Remote Controller

HBC

PLC module

Siemens

Hydraulic system

Hydraulic System Type

open loop

System Working Pressure

32mPA

Main Hydraulic Pump

Nikkawa

Main Hydraulic Pump Type

Kawasaki 140

Main Hydraulic Pump Displacement

140ml/r

Main Electro-Hydraulic Valve

Eaton

Multi-Way Valve

Wolfe

Hydraulic Seals

Parker

Hydraulic Hose

Italian Manuli

Hydraulic Oil Tank Capacity

600L

Hydraulic Oil Cooling

Air cooling

High And Low Pressure Exchanger

available

Hydraulic Cylinder Bore/Stroke

Φ125*1400mm

Clean system

Water Tank Capacity

500L

Dimension and weight

Overall Length

9630mm

Overall Width

2480mm

Overall Height

3423mm

Total Weight

15000 kg

Separate body weight

6000kg

Pumping system

Concrete Valve

S Valve

Max.Concrete Output(high/low voltage)

50/80m³/h

Max.Concrete Pressure(high/low voltage)

13/7.5MPa

Hydraulic Strokes(high/low voltage)

19/32min-1

Concrete Cylinder Bore/Stroke

Φ200*1400mm

Hopper Charge Height

1540mm

Concrete Hopper Capacity

0.55m³

Concrete Slump

120-230mm

max. aggregate dimension

40mm

Tips: Welcome to leave mess age below to get the detailed configuration of our other models.
